Case Report: A right-sided testicular artery of renal origin, in coexistence with a renal artery duplication: Dissection findings with clinical significance

[version 1; peer review: 2 approved with reservations]

Natsis Konstantinos¹^*, Ediaroglou Vasilios¹^*, Totlis Trifon¹, [...] Tsakotos George², Triantafyllou George², Petrou Vasileios¹, Piagkou Maria ²

Natsis Konstantinos¹^*, Ediaroglou Vasilios¹^*, [...] Totlis Trifon¹, Tsakotos George², Triantafyllou George², Petrou Vasileios¹, Piagkou Maria ²

^* Equal contributors

PUBLISHED 23 Aug 2024

Author details Author details

¹ Department of Anatomy and Surgical Anatomy, School of Medicine, Faculty of Health Sciences, Aristotle University of Thessaloniki, Thessaloniki, Greece
² Department of Anatomy, School of Medicine, Faculty of Health Sciences, National and Kapodistrian University of Athens, Athens, Greece

Natsis Konstantinos
Roles: Conceptualization, Investigation, Methodology, Project Administration, Writing – Original Draft Preparation

Ediaroglou Vasilios
Roles: Investigation, Methodology, Writing – Original Draft Preparation

Totlis Trifon
Roles: Investigation, Methodology, Writing – Original Draft Preparation

Tsakotos George
Roles: Investigation, Methodology, Writing – Review & Editing

Triantafyllou George
Roles: Investigation, Methodology, Writing – Review & Editing

Petrou Vasileios
Roles: Investigation, Methodology, Writing – Review & Editing

Piagkou Maria
Roles: Investigation, Methodology, Supervision, Writing – Original Draft Preparation, Writing – Review & Editing

OPEN PEER REVIEW

REVIEWER STATUS

This article is included in the HEAL1000 gateway.

Abstract

Purpose

The current cadaveric report describes the abnormal origin and course of testicular arteries (TAs) in two donated cadavers, along with a renal artery (RA) duplication.

Methods

Dissection of the inferior vena cava (IVC) and the abdominal aorta (AA) branching patterns were performed in 90-year-old- and 76-year-old formalin-embalmed donated male cadavers.

Results

Variants of the TA origin and course were identified, as coexisting with RA variants. Case 1: A right-sided RA (RRA) duplication (recorded as superior and inferior renal artery-SRA and IRA) with origin from the AA, coexisted with a right TA (RTA) that originated from the IRA and descended anteriorly to the ureter. The left TA (LTA) originated from the AA proximal to the origin of the left RA (LRA). The LTA coursed in front of the common drainage of the left testicular and renal vein into the IVC. Case 2: A bilateral RA duplication was identified and recorded as SRA and IRA. The right-sided SRA originated from the AA upper level and played the role of the accessory RA (ARA). The main perfusion of the right kidney was performed by the IRA which was further trifurcated into a superior polar, an inferior polar (IPA), and a TA. The RTA had a high origin from the IPA.

Conclusion

The current study reported two cases of TAs with abnormal origin and course accompanied by an RA duplication. A thorough knowledge of the origin and course of the TAs has clinical implications for the kidneys and testicle’ surgery.

Keywords

testicular artery, variation, renal artery, origin, duplication

Corresponding author: Piagkou Maria

Competing interests: No competing interests were disclosed.

Grant information: The publication of the article in open access mode was financially supported by HEAL-Link.

Copyright: © 2024 Konstantinos N et al. This is an open access article distributed under the terms of the Creative Commons Attribution License, which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited.

How to cite: Konstantinos N, Vasilios E, Trifon T et al. Case Report: A right-sided testicular artery of renal origin, in coexistence with a renal artery duplication: Dissection findings with clinical significance [version 1; peer review: 2 approved with reservations]. F1000Research 2024, 13:953 (https://doi.org/10.12688/f1000research.150839.1) First published: 23 Aug 2024, 13:953 (https://doi.org/10.12688/f1000research.150839.1) Latest published: 23 Aug 2024, 13:953 (https://doi.org/10.12688/f1000research.150839.1)

Introduction

Typical and variant anatomy of the testicular arteries (TAs) or internal spermatic arteries should be carefully studied respectively to their laterality (side of appearance), because of their clinical role in testicular physiology and kidney and testicle surgery. Typically, the long and thin TA originates from the abdominal aorta (AA) anterolateral surface, at a distance of 2.5 to 5 cm distally to the renal artery (RA) origin, and above the inferior mesenteric artery origin.¹ The TA supplies the perirenal fat, ureter, iliac lymph nodes, and the cremaster muscle.¹^–³ It is directed with the testicular vein (TV), retroperitoneal, on the psoas major muscle, enters the inguinal canal through the deep ring, and supplies the testicle.⁴ The right TA (RTA) originates anterior to the inferior vena cava (IVC) and lies posterior to the duodenum horizontal part, right colic and ileocolic arteries, root of the mesentery, and terminal ileum.¹^,² The left TA (LTA) courses posterior to the inferior mesenteric vein, left colic artery, and descending colon.¹^,² The right and left testicular veins (RTV and LTV) typically drain into the IVC, and the left renal vein (LRV), respectively.⁵

TA variants are not rare, as cadaveric studies have shown a prevalence ranging from 4.7% to 8.8%.⁵^,⁶ The TAs may exhibit an arched course ranging from 1.7% to 20.3%.¹ TA variants may be accompanied by TV alterations and the awareness of these venous anomalies may help surgeons accurately ligate abnormal venous anastomosis and avoid iatrogenic injury. TA variants may also coexist with RA alterations. Concerning the RAs, typically, a single RA emanates from the AA, on both sides.⁷ Frequent variants include the RA variant number⁷ among different ethnicities (4% in Malaysians, and 61.5% in Indians).⁸ The presence of multiple RAs is a well-documented phenomenon with a reported frequency of around 20%.⁷^,⁸

The present cadaveric report explicitly describes the atypical origin and course of TAs along with an RA duplication and further discusses their clinical implications.

Cases report

During a routine dissection of the IVC and AA branching patterns in two formalin-embalmed donated male cadavers 90-year- and 76-year-old, several variants of the TAs origin and course were identified, as coexisting with RA variants. The cadavers were donated to the Anatomy and Surgical Anatomy Department of the Medical School of the Faculty of Health Sciences of the Aristotle University of Thessaloniki, and the Anatomy Department of the Medical School of the National and Kapodistrian University of Athens, after signed informed consent. The Ethics Committees of the two Universities gave full approval for the study. Case 1: A right-sided RA duplication (RRA) (recorded as superior and inferior renal artery-SRA and IRA) with origin from the AA, coexisted with an RTA that originated from the IRA, and descended anteriorly to the ureter. The LTA typically originated from the AA proximal to the left RA (LRA) origin. The LTA coursed in front of the common drainage of the LTV and LRV to the IVC (Figure 1). Case 2: A bilateral duplication of the RA was identified and recorded as SRA and IRA (Figures 2,3). The right-sided SRA originated from the AA upper level and played the role of the accessory RA (ARA). The main perfusion of the right kidney was performed by the IRA which was further trifurcated into a superior polar artery (SPA), an inferior polar artery (IPA), and a TA. The RTA had an origin from the IPA and descended anterior to the RRV (Figure 2).

Figure 1. Right side-RA. Duplication of the renal artery (superior renal artery-SRA and inferior renal artery-IRA) and their origin from the abdominal aorta. The testicular artery (TA) originated from the IRA and descended anteriorly to the ureter (U). Left side-LB. TA originated from the abdominal aorta (AA) superior to the origin of the renal artery and coursed anteriorly to the common drainage point of the testicular vein (TV) and renal vein (RV) via a common stem with a suprarenal vein (SRV) into the inferior vena cava (IVC), U-ureter, and SRV–suprarenal vein. The LTA anterior course to the left renal vein mimics an unusual variety of nutcracker phenomena.

Figure 2. RA, RB. The renal artery duplication (superior renal artery-SRA and inferior renal artery-IRA). The IRA trifurcation into a superior polar artery (1), an inferior polar artery (2), and a testicular artery (3-TA). The high origin of the testicular artery (3) from the inferior polar artery. The SRA originates from the upper level of the abdominal aorta (AA), AA-abdominal aorta, RK-right kidney, IVC-inferior vena cava, and RV-renal vein.

Figure 3. LA, LB. Left-sided renal artery duplication (SRA-superior renal and IRA-inferior renal artery). The SRAdivision into a thick branch (1) and a thin branch (2). The similar distribution for the veins, SPV-superior polar vein, IPV-inferior polar vein, and the formation of the IPV from the 2’ and 3’ veins followed the same distribution with the arteries 2 and IRA. The 1’ had the same distribution as the arterial branch 1. LK-left kidney, U-ureter.

Discussion

The current study describes the TA’s abnormal origin and course in coexistence with an RA duplication.

Embryological development of the testicular and renal arteries (TAs and RAs)

Understanding the developmental stages of arteries provides the basis for understanding morphological variants.⁵ Regarding the embryological progression of the gonads, which are drained by the mesonephric arteries originating from the AA lateral surface ²^,⁹^,¹⁰ there are nine pairs¹^–⁴^,⁶^,¹¹^,¹² which can be categorized into a cranial group which consists of the 1^st and 2^nd mesonephric arteries that mature into the celiac trunk, the middle group which consists of the 3^rd, 4^th, and 5^th arteries that develop into the RAs, and a caudal group which consists of the 6^th, 7^th, 8^th, and 9^th mesonephric arteries which become the TAs.² An extra artery in the middle group will typically evolve into the ARA.²^,⁴ If a cranial mesonephric artery does not regress, it will lead to a high-origin TA.¹^,²^,⁶^,¹²

Regarding the 1^st cadaveric report, we hypothesize an additional mesonephric artery in the middle group on the right side led to the RRA duplication. On the left side, there was a persistent cranial lateral mesonephric artery which would explain the LTA’s abnormal origin. The LTA arched course anteriorly to the LRV and the LTV common drainage could be due to the kidney’s position and the higher vertebral level of the LRV compared to the LTA’s origin.¹^,²^,¹² This anterior course mimics an unusual variety of nutcracker phenomena.¹³ The RTAs’ atypical origin of both cadavers can be explained by a possible bifurcation of an additional artery from the middle group of the mesonephric arteries.¹^,⁴ One branch would drain the genital ridge and the other would supply the kidney. The TA would come from the former of the two branches.

In the 2^nd cadaver, an extra pair of mesonephric arteries in the middle group would explain the RA bilateral duplication.²^,⁴ On the right side, there was not only one more mesonephric artery that evolved into the ARA but also the other mesonephric artery bifurcation would explain the IRA duplication. TA variants are more common in males than females,²^,⁶^,¹² and the LTA variants (20.7%) are more common than the RTA variants (12.7%).⁹

Variants of the testicular arteries (TAs) origin (location and vessel)

The TAs typically originate from the AA anterolateral surface, just below the RA origin, at the 2^nd or 3^rd lumbar vertebrae level (L2 or L3).²^,⁹ The most common variants include alterations in the level, source of origin, number, and course of arteries. TA’s origin can be more proximal than the RA and RV.¹⁴ TA’s abnormal origins include the right subcostal artery, the suprarenal artery, the celiac trunk, the right inferior epigastric artery, the superior mesenteric artery (SMA), the inferior mesenteric artery (IMA), the right common iliac, and right external iliac artery.¹^–³^,⁹^,¹⁵ TA may originate at the level of the SMA, level of the RA or above,⁹ in a common trunk with the IMA, and an ARA,¹⁵ or in a common trunk with the LTA and RTA from the AA.¹⁶ Atypical origins proximal to the L2/L3 level are classified as high-origins, and distal to the L2/L3 or the IMA level are considered low-origins.²^,⁹ The highest origin for the TA was identified at the left side, from the thoracic aorta, proximal to the inferior phrenic artery,¹⁰ or above the aortic diaphragmatic hiatus (level of the 12^th thoracic vertebra).⁴ An LTA was identified originating from the LRA in 5.26% and the RTA from the RRA in 2.63%.⁹ The TA may originate from the main RA, an ARA, or a polar RA.¹^–⁴^,⁶^,⁹^,¹⁵^,¹⁶ The most common TA variant origins were found in association with renal vessels. Regarding their number, double TA was the most common.¹ Concerning the combined TA variants with RA alterations, in the current report, Naito et al.¹⁷ recorded the coexistence of multiple RAs (8 in total, arising from the AA) with a bilateral renal origin for the TAs, and Notokovich¹⁸ reported gonadal arteries of renal origin in 15%. The number of RAs can be up to six, the most common being 2RAs, similar to the current cadaveric cases. Multiple RAs are reported as the most common renal vascular variant by Satyapal et,¹⁹ with an average incidence of 28.2% (range 9-76%). Two or double RAs are reported to make up 89.5% of all multiple RAs.⁸ Merklin and Michels²⁰ reported incidences for 2RAs, 3RAs, and 4RAs unilaterally of 20%, 2%, and 0%, respectively. Ozkan et al.²¹ and Sampaio and Passos²² reported an incidence of 0.2% and 0.4% for 4RAs, respectively.

Concerning the TA variant course, the most common variation was an arched course over the ipsilateral RV. Occurrence of the arched TA has been noted on both sides but with a predilection for the left side. An arched RTA had an occasional retrocaval course.¹ Kayalvizhi et al.¹ concluded an incidence ranging from 1.7% to 20.3% for the arched TA. The arched LTA course over the LRV, similar to the current two unilateral (left and right side) cases is particularly important as it can compress the LRV and impede the venous return from the left kidney and testis. Consequently, varicocele, orthostatic proteinuria, and hematuria can occur. All the observed variants in these two cases could be due to aberrations in the development of visceral vessels controlled by a common molecular regulator.²³ Most of these variants are part of the age of the cadaver. Our findings reiterate the old dictum that if an anomaly is detected in one vessel, there are chances of encountering other related anomalies as well. Clinicians need to check for the presence of an arched TA when performing renal surgery, as any injury to this artery might cause testicular atrophy.²⁴

Clinical aspects of testicular artery and coexisted variants

TAs variants although occur frequently, are accidentally discovered intraoperatively.⁹ The knowledge of the origin and the course of the TAs is clinically important for kidney and testicle surgery and can prevent intraoperative and postoperative complications.¹^–⁴^,⁶^,⁷^,⁹^,¹⁶ Surgeons should consider the RAs’ origin and path when they operate proximal to the renal pelvis or retroperitoneal and particularly target their usage in case of cryptorchism.¹^,⁴ The TAs’ abnormal origin and course around the kidney may lead to unexpected serious intraoperative hemorrhage.¹^,⁶^,⁹ Radiologists should consider the possibility of variants when performing an angiography with indications, such as recognition of the arterial branches and planning the surgical procedure.¹^–⁶^,⁹^,¹⁵ If any abnormal origin or path of an artery is perceived via angiography, further examinations like magnetic resonance imaging (MRI) and phlebography should be performed to reduce the possibilities of intraoperative and postoperative complications.¹ Furthermore, knowledge of the numerous variants of the renal vessels is surgically important in cases of repair renal stenosis, renal infarctions, and renal hypertension, as well as other urological surgeries.¹^,⁹^,¹² Renal arterial hypertension may occur by RA compression and could progress to renal ischemia.¹^,⁴^,¹⁵ The variations could also affect the perfusion and function of testicles.³^,⁴^,⁵ Knowledge of these variations can aid in the prevention of testicular atrophy.¹^,³^,⁵ These variations could also have serious implications regarding the thermoregulation of the male reproductive tract and consequently have an impact on spermatogenesis.³^–⁵ The lower frequency of the RTA variants compared to the LTA provides an advantage in the usage of the right kidney in transplantations.⁴ Kidneys with multiple vessels are in high demand for transplantation due to their ability to help more patients who require a transplant.⁴ Furthermore, a TA originating from the RA may disturb the testicles’ drainage when embolizing renal tumors.²^,⁹^,¹⁴^,²⁵ A case report recorded that during the embolization of a vessel in a renal tumor, an infarction occurred because of an abnormal TA origin from the RA, despite attempts to prevent it.²⁵ Another similar case of testicular infraction has been reported which proceeded from an embolization of a renal angiolipoma.¹⁴ Because of the TA arched and anterior course with the RV, there is a potential for RV compression, as seen in the current case description, causing a varicocele secondary to vascular compression.¹^,²^,¹⁵ RV compression could also cause venous hypertension, proteinuria, and orthostatic hematuria secondary to the tortuous vascular course.²^,¹⁵ The TA’s abnormal course could compress the ureter and potentially lead to hydronephrosis.¹^,⁴^,⁶

Conclusion

In the current cadaveric report, upon performing simultaneous dissections in different locations, similar variants were discovered in the TAs origin and course with RAs duplications in two cadavers. Surgeons should consider the origin and path of the TAs and the possible coexistence of the RAs alterations to prevent intraoperative and postoperative complications.

Consent

The cadavers were donated to the Department of Anatomy and Surgical Anatomy, School of Medicine, Aristotle University of Thessaloneiki and the Anatomy Department of the Medical School of the National and Kapodistrian University of Athens through the Body Donation Program of the universities. The donor signed an informed consent before death giving consent to medical, education and research projects.

Data availability

No data are associated with this article.

Acknowledgments

The authors would like to express their gratitude to body donors and their families for their highest contribution to medical education and anatomy research.

References

1. Kayalvizhi I, Narayan RK, Kumar P: Anatomical variations of testicular artery: a review. Folia Morphol. (Warsz). 2017; 76(4): 541–550. Epub 2017 Apr 10. PubMed Abstract | Publisher Full Text
2. Paraskevas GK, Natsis K, Nitsa Z, et al.: Bilateral double testicular arteries: a case report and review of the literature. Potential embryological and surgical considerations. Folia Morphol (Warsz). 2014; 73(3): 383–388. PubMed Abstract | Publisher Full Text
3. Paraskevas GK, Ioannidis O, Raikos A, et al.: High origin of a testicular artery: a case report and review of the literature. J. Med. Case Rep. 2011; 5: 75. PubMed Abstract | Publisher Full Text | Free Full Text
4. Mamatha H, D’Souza AS, Vinodhini P, et al.: A Cadaveric Study about the Anomalous Origin of Testicular Arteries Arising from the Accessory Renal Arteries. Indian J. Surg. 2015; 77(2): 111–6. Epub 2012 Oct 30. PubMed Abstract | Publisher Full Text | Free Full Text
5. Asala S, Chaudhary SC, Masumbuko-Kahamba N, et al.: Anatomical variations in the human testicular blood vessels. Ann. Anat. 2001; 183(6): 545–549. PubMed Abstract | Publisher Full Text
6. Ciçekcibaşi AE, Salbacak A, Seker M, et al.: The origin of gonadal arteries in human fetuses: anatomical variations. Ann. Anat. 2002; 184(3): 275–279. PubMed Abstract | Publisher Full Text
7. Cases C, García-Zoghby L, Manzorro P, et al.: Anatomical variations of the renal arteries: Cadaveric and radiologic study, review of the literature, and proposal of a new classification of clinical interest. Ann. Anat. 2017; 211: 61–68. Epub 2017 Feb 3. PubMed Abstract | Publisher Full Text
8. Recto C, Pilia AM, Campi R, et al.: Renal artery variations: a 20,782 kidneys review. Ital. J. Anat. Embriol. 2019; 124(2): 153–163. Publisher Full Text
9. Nallikuzhy TJ, Rajasekhar SSSN, Malik S, et al.: Variations of the testicular artery and vein: A meta-analysis with proposed classification. Clin. Anat. 2018; 31(6): 854–869. PubMed Abstract | Publisher Full Text
10. Shinohara H, Nakatani T, Fukuo Y, et al.: Case with a high-positioned origin of the testicular artery. Anat. Rec. 1990; 226(2): 264–266. PubMed Abstract | Publisher Full Text
11. Lee HB, Yang J, Maeng YH, et al.: Bilateral multiple renal arteries with an extra-aortic origin and quadruple testicular veins. Anat. Cell Biol. 2019; 52(4): 518–521. Epub 2019 Dec 16. PubMed Abstract | Publisher Full Text | Free Full Text
12. Pai MM, Vadgaonkar R, Rai R, et al.: A cadaveric study of the testicular artery in the South Indian population. Singapore Med. J. 2008; 49(7): 551–555. PubMed Abstract
13. Braedel HU, Steffens J, Ziegler M, et al.: A possible ontogenic etiology for idiopathic left varicocele. J. Urol. 1994; 151: 62–66. PubMed Abstract | Publisher Full Text
14. Siniluoto TM, Hellström PA, Päivänsalo MJ, et al.: Testicular infarction following ethanol embolization of a renal neoplasm. Cardiovasc. Intervent. Radiol. 1988; 11(3): 162–164. PubMed Abstract | Publisher Full Text
15. Chakravarthi KK: Unilateral multiple variations of renal, phrenic, suprarenal, inferior mesenteric, and gonadal arteries. J. Nat. Sci. Biol. Med. 2014; 5(1): 173–175. PubMed Abstract | Publisher Full Text | Free Full Text
16. Adebisi SS, Singh SP: Anomalous gonadal arteries in relation to the renal vein: A preliminary study in nigerians. Niger. J. Surg. Res. 2000; 2: 148–151. Publisher Full Text
17. Naito M, Hirai S, Terayama H, et al.: Multiple renal vessels associated with testicular vessels. Surg. Radiol. Anat. 2011; 33: 637–639. PubMed Abstract | Publisher Full Text
18. Notokovich H: Variations of the testicular and ovarian arteries in relation to the renal pedicle. Surg Gynecol Obstet 1956; 103: 487–495.
19. Satyapal KS, HaVejee AA, Singh B, et al.: Additional renal arteries incidence and morphometry. Surg. Radiol. Anat. 2001; 23: 33–38. PubMed Abstract | Publisher Full Text
20. Merklin RJ, Michels NA: The variant renal and suprarenal blood supply with data on the inferior phrenic, ureteral, and gonadal arteries: a statistical analysis based on 185 dissections and review of the literature. J. Int. Coll. Surg. 1958; 29: 41–76. PubMed Abstract
21. Ozkan U, Ofuzkurt L, Tercan F, et al.: Renal artery origins and variations: angiographic evaluation of 855 consecutive patients. Diagn. Interv. Radiol. 2006; 12: 183–186. PubMed Abstract
22. Sampaio BJB, Marf P: Renal arteries: anatomic study for surgical and radiological practice. Surg. Radiol. Anat. 1992; 14: 113–117. PubMed Abstract | Publisher Full Text
23. Wadhwa A, Soni S: A study of Gonadal Arteries in 30 adult human cadavers. Clin Med Insights Reprod Heal. 2010; 4: CMRH.S3680–CMRH.S3685. Publisher Full Text
24. Padur AA, Kumar N: Unique variation of the left testicular artery passing through a vascular hiatus in renal vein. Anat Cell Biol. 2019; 52(1): 105–107. Epub 2019 Mar 29. PubMed Abstract | Publisher Full Text | Free Full Text
25. Cummings CT, Foreman R, Killoran TP, et al.: Testicular infarction after angioembolization of an ipsilateral renal angiomyolipoma. Urology. 2013; 82(5): 995–7. Epub 2013 Aug 23. PubMed Abstract | Publisher Full Text
