Case Report: Tongue deviation due to supranuclear injury with a rare semiological feature

Introduction

The causes of hypoglossal nerve palsy can vary widely and include tumors, trauma, ischemia, and demyelinating lesions. These lesions can be classified according to their location as infranuclear, nuclear, and supranuclear.^1,2

Infranuclear lesions directly affect the hypoglossal nerve before it exits the medulla oblongata. On the other hand, nuclear lesions involve the motor nuclei of the hypoglossal nerve in the medulla oblongata. Isolated lesions at the nuclear level are uncommon and are usually accompanied by lesions in other nearby cranial nerves due to their position in the brainstem and their posterior course. These lesions cause a deviation of the tongue towards the opposite side of the affected one; due to the predominant contraction of the healthy half of the tongue.^3,4 Furthermore, they are usually associated with lower motor neuron signs such as atrophy and fasciculations.¹

From another view, supranuclear lesions occur at higher areas such as the cerebral cortex, corticobulbar tract, cerebellar peduncles, and pons. Supranuclear control of the tongue originates in the most lower and lateral part of the precentral gyrus, in the primary motor area. Corticobulbar fibers originate from this area and provide bilateral innervation to the hypoglossal nuclei, except for the nuclei portion that innervates genioglossus muscle, which only receives innervation from the contralateral cortex. This explains why supranuclear lesions are often silent, as the corticohypoglossal fibers of the contralateral cortex to the lesion remain intact. This develop in a functional compensation, resulting in a mild weakness of the tongue muscles, which in most cases, may not be evident.^5–7

Case report

We present the case of a 43-year-old male patient from Cartagena, Colombia, right-handed motorcycle driver, with a history of left distal radius fracture that required surgical management. The patient has no known cardiovascular history. He was referred from a primary care center due to a 6-hour clinical picture, which began upon awakening, consisting of dysarthria and deviation of the labial commissure to the left side. On admission, an electrocardiogram was performed showing atrial fibrillation and elevated blood glucose levels.

On physical examination he was found tachycardic, with normal oxygen saturation and blood pressure. The auscultation showed arrhythmic heart sounds and the rest of the general physical examination without significant alterations. On neurological examination the patient was alert, dysarthric, however, fluent, understand, name, and repeat; with preserved orientation. There was evidence of left central facial paralysis (Figure 1) and tongue deviation to the left (Figure 2). Left upper limb monoparesis 4/5 in muscle strength scale, with distal predominace at regional evaluation. Reflexes were symmetrical with normal gait and coordination. Complementary studies showed normal blood cell count, moderate hypokalemia, persistently elevated blood glucose levels and uroanalysis with glycosuria, with preserved renal function. Atrial fibrillation on electrocardiogram. Based on these findings, it was considered an acute stroke of probable cardioembolic etiology, which is confirmed with brain MRI that evidenced right frontal corticosubcortical lacunar image with gliosis in T2 and FLAIR sequence and that restrings in diffusion (Figure 3).

Figure 1. Centra facial palsy on the left side of the face.

Figure 2. The left side of the tongue shows an important paralysis.

Figure 3. MRI axial brain T2 FLAIR (a) and Diffusion (b) shows an ischemic lesion with hemorrhagic changes.

Echocardiogram reported mitral valve prolapse with mild insufficiency and normal biventricular systolicdiastolic function with preserved ejection fraction. Carotid ultrasound reported no alterations, and 24-hour holter with basal atrial fibrillation rhythm with variable ventricular response throughout the study.

Diagnosis of ischemic stroke of cardioembolic etiology was made, first-diagnosis atrial fibrillation o with rapid ventricular response CHA2DS2-VASc 1 and HAS-BLED 1 and de novo type 2 diabetes mellitus. At discharge he continued antiarrhythmic treatment and insulin therapy with oral antidiabetic and direct oral anticoagulant.

Discussion

The hypoglossal nerve nucleus is located in the tegmentum of the medulla oblongata, located between the midline and the dorsal motor nucleus of the vagus nerve. This thin-structured nucleus receives innervation from the precentral gyrus and is fed with information coming from areas such as the inferior frontal cortex and the premotor cortex.⁶ This information is transmitted through corticobulbar tracts and distributed bilaterally to the hypoglossal nerve nuclei, resulting in unilateral lesions that have a clinically insignificant effect.

In a study involving 300 patients with unilateral cerebral infarctions, it was observed that 29% of them had tongue deviation towards the side of the motor deficit. Most of these cases were associated with ipsilateral face and arm weakness. It was found that a lesion in the precentral gyrus in the tongue area could cause a contralateral palsy of the hypoglossal nerve, a phenomenon known as “pseudoperipheral tongue palsy.” In this type of situation, the tongue deviated towards the opposite side to the lesion, but atrophy or fasciculations were not observed, as took place in the present case.⁸

Disruption of the corticolingual pathway plays a crucial role in the development of dysarthria after cerebrovascular events, due to the presence of a central monoparesis of the tongue.^9,10

Supranuclear paralyses of the hypoglossal nerve of vascular origin, which cause tongue deviation, tend to be accompanied by other signs such as hemiparesis, or less frequently, weakness in the facial, pharyngeal or masticatory musculature of the same side. These presentations set up an opercular syndrome on the affected side.¹¹ However, in our case, the presentation was atypical since a tongue deviation and facial weakness were observed, without marked hemiparesis, in the context of a unilateral supranuclear lesion.

Consent

We obtained written informed consent for publication of their clinical details and clinical images from the participants.
