Effect of vitamin E supplementation on orthodontic tooth movement in Wistar rats

[version 1; peer review: 1 approved, 1 not approved]

Erliera Sufarnap ¹, Darmayanti Siregar², Yumi Lindawati³

PUBLISHED 04 Sep 2020

Author details Author details

¹ Department of Orthodontics, Universitas Sumatera Utara, Medan, North Sumatera, 20155, Indonesia
² Department of Dental Public Health, Universitas of Sumatera Utara, Medan, North Sumatera, 20155, Indonesia
³ Department of Oral Biology, Universitas Sumatera Utara, Medan, North Sumatera, 20155, Indonesia

Erliera Sufarnap
Roles: Conceptualization, Data Curation, Formal Analysis, Funding Acquisition, Investigation, Project Administration, Resources, Supervision, Validation

Darmayanti Siregar
Roles: Formal Analysis, Methodology, Software

Yumi Lindawati
Roles: Visualization, Writing – Review & Editing

OPEN PEER REVIEW

REVIEWER STATUS

Abstract

Background: Tooth movement induced by the application of orthodontic force is facilitated by bone remodelling cells and chemical mediators. Vitamin E has anti-inflammatory properties, which helps in suppressing the damaging effects of oxygen free radicals in cells during bone formation. This study aimed to evaluate the effect of vitamin E supplementation on orthodontic tooth movement in Wistar rats.
Methods: Wistar rats (n=56) were divided into two groups. Group 1 served as the control groups, while group 2 was given vitamin E for 14 days before application of orthodontic force. Each group was divided into four subgroups (n=7), corresponding to the number of days orthodontic force lasted, i.e. 0, 1, 3, 7 days. At each of these four time points, distance measurements and quantity of osteoblasts-osteoclasts were measured in each rat.
Results: Tooth movement distance was increased for group 2 than group 1 for all time intervals, but this difference was only statistically different on day 3 (p=0.001). For both groups, tooth movement was significantly different between each time interval in each group (p=0.041). The mean number of osteoblast cells was increased for group 2 compared to group 1 for all time intervals (p<0.05), but was not significant different between time intervals (p=0.897). The number of osteoclasts was not significantly different between groups, but it was statistically different between time intervals (p=0.004).
Conclusion: Present outcomes demonstrate that vitamin E contributes to faster tooth movement compared to control group. It also stimulates more bone formation without reducing the bone resorption.

Keywords

Orthodontic tooth movement, vitamin E, tooth movement distance, osteoblast, osteoclast.

Corresponding author: Erliera Sufarnap

Competing interests: No competing interests were disclosed.

Grant information: This study project is financed by Research Institution of Universitas Sumatera Utara (263/UN5.2.3.1/PPM/KP-TALENTA-USU/2019).
The funders had no role in study design, data collection and analysis, decision to publish, or preparation of the manuscript.

Copyright: © 2020 Sufarnap E et al. This is an open access article distributed under the terms of the Creative Commons Attribution License, which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited.

How to cite: Sufarnap E, Siregar D and Lindawati Y. Effect of vitamin E supplementation on orthodontic tooth movement in Wistar rats [version 1; peer review: 1 approved, 1 not approved]. F1000Research 2020, 9:1093 (https://doi.org/10.12688/f1000research.25709.1) First published: 04 Sep 2020, 9:1093 (https://doi.org/10.12688/f1000research.25709.1) Latest published: 07 Dec 2020, 9:1093 (https://doi.org/10.12688/f1000research.25709.3)

Introduction

Tooth movement is induced by the application of orthodontic force characterized by bone and periodontal tissue remodelling. Orthodontic force also alters periodontal tissue vascularity and blood flow, resulting in the local synthesis and release of various molecules such as neurotransmitters, cytokines, growth factors, colony-stimulating factors and arachidonic acid metabolites¹.

Bone remodelling is a process that enables tooth movement. It involves bone-reabsorption by osteoclasts on the pressure site and bone-formation by osteoblasts on the tension site^2,3. Osteoclasts are multinucleated cells, irregular in shape with a process originating from Howship’s lacunae⁴. They stimulate bone resorption by creating cavities in the bone known as lacunae that will be filled by osteoblast cells³. According to Mavragani et al., the cellular process of osteoclast proliferation has been used as important indicators in evaluating the level of tooth movement⁵. Osteoblasts are mononuclear cells that originate from mesenchymal stem cells in bone marrow. Mature osteoblasts form the osteoid by synthesizing collagen and non-collagen proteins⁶.

According to Burstone in Asiry’s citation, there are three phases of orthodontic tooth movement, which consists the initial, lag and postlag phases⁷. The initial stage of orthodontic tooth movement stimulates an inflammatory response involving cells and blood vessels in periodontal ligaments as well as chemical mediators. In response to mechanical stress caused by the application of orthodontic force, substances such as cytokines and enzymes are released^2,8. Interleukin-1β is a pro-inflammatory cytokine that facilitates fusion and activation of osteoclasts, and encourages early bone resorption⁹.

Studies have shown that vitamin E has anti-inflammatory properties, which helps suppress damaging effects of oxygen free radicals in cells during bone formation¹⁰. Previous studies carried out by Esenlik et al. and Xu et al. suggest that vitamin E supplementation may alter cytokine production; vitamin E supplement maintains normal bone remodelling in young animals and increases bone mass by decreasing the concentration of free radicals which suppress bone formation^11,12.

Since orthodontic tooth movement is facilitated by bone remodelling cells and chemical mediators, it is possible to hypothesize that vitamin E has a positive effect on bone remodelling cells, which is crucial to tooth movement. However, it is unknown if vitamin would accelerate the movement or inhibit tooth movement. The purpose of this study was to evaluate the effect of vitamin E supplementation on orthodontic tooth movement in Wistar rats. Mice and rats are mammals that have a reasonably comparable metabolism to humans, which can be used for biological-cellular mechanism analysis in orthodontic tooth movement¹³.

Methods

Animals

This article was reported in line with the ARRIVE guidelines. The study was an in-vivo quasi experiment, which was approved by the Animal Research Ethics Committee, Department of Biology - Faculty of Mathematics and Science, Universitas Sumatera Utara (No. 0128/KEPH-FMIPA/2019).

A total of 56 healthy male, four to five-months old, Wistar rats, weighing 150–250 grams, were used in this study. The Wistar Rats came from the same breeding farm (Deli Serdang, North Sumatera, Indonesia) in two cycles.

The rats were adapted to their environment for 7 days before the experiment start. They were nurtured at the Animal House at Faculty of Mathematics and Science, Universitas Sumatera Utara in polycarbonate cage, which measured 480 mm × 265 mm × 210 mm. Each cage had wood shavings on the floor, and contained 3 or 4 animals, which were marked for each subgroup. Rats were chosen for each group by simple random sampling.

Low light to dark cycle was maintained for a minimum 12 hours at 25–30°C for room temperature within the experiment period. The rats were given a standard pellet diet. All conditions served to produce the optimum condition of the rats’ habitat¹⁴. A rubber separator was inserted between maxillae’s incisors to produce non-invasive experiments. Anaesthetic was used to euthanize the rats at the end of the experimental procedure.

Experiment

Wistar rats (n=56) were divided into two groups. Each group was then divided into four subgroups (n=7), corresponding to the number of the days orthodontic force lasted, i.e. 0, 1, 3, 7 days. The sample size of each subgroup was decided by Sastroasmoro and Ismael’s formula for hypothetical analysis between independent variables¹⁵.

Subgroups were chosen based on the rats’ social behaviours. Hyperactive rats were chosen to be in the same cage, separately to rats with a more passive behaviour. These conditions avoided any anxiety social-related behaviour between rats in the cage within the experiment. For each experiment, a researcher who was blind to the experiment chose a sample randomly from each cage.

Group 1 were the control group and were given water orally as a placebo. The rats’ tail was marked with black pen. Group 2 were the experimental group and were given vitamin E (dl-α-Tocopheryl Acetate; Sanbe, Indonesia) at a dosage of 60 mg/kg, orally using gavage needle. The group 2 rats’ tail marked with red pen.

Water and vitamin E were given every day at 8am, for 14 days before and continued after application of orthodontic force. After 14 days, orthodontic force was applied to each rat in both groups by addition of a rubber separator to one of the maxilla incisors (Figure 1A). This administration of orthodontic force applied were carried out before daily water and vitamin E feeding. This procedure counted as the baseline time of the experiment. At each of these four time points distance measurements and quantity of osteoblasts-osteoclasts were measured (see section below).

Figure 1.

(A) Rat separator; (B) Distance measurement; (C) Microscopic of whole teeth at 40x magnification. Lines, Yellow=teeth; Green=periodontal ligament; Red=alveolar bone. Arrows, Blue=pressure side; Green=tension side.

At end of each experiment period, the dosage of ketamine® at 80mg/kg of body weight and xyla® (Interchemie, Holland) at 10mg/kg of body weight was used to euthanised each rat by cardiac puncture methods for further research with blood analysis.

Outcomes

Tooth movement was measured using a digital calliper (Mitutoyo, Japan) was used to measure the distance between maxilla incisors at mesial cervical (Moorrees method) immediately after removal of the rubber separator (Figure 1B)¹⁶.

The pre-maxillae were dissected and fixated in 10% formalin for 24h, and decalcified with rapid-decalsifier, Nitric acid 10% (Aurona Scientific, Singapore) for 10-14 days. The embedded blocks were trimmed using a Leica microtome (Leica, Germany) into 5µm sections. Histological sections were stained with haematoxylin-eosin and were examined using Olympus CX21 light microscope at 400x magnification to analyse the number of cells within five fields of view for each measurement. A pressured site exhibited as a narrow area between teeth and alveolar bone where the tooth tended to move, and this site was used for osteoclast analysis. A tension site exhibited as a wide area between teeth and alveolar bone where the tooth was left out, and this site was used for osteoblast analysis (Figure 1C).

Statistical analysis

IBM-SPSS (Statistical Package for Social Sciences), version 26.0, was used for statistical analysis. Independent t-test and Mann-Whitney test were used to analyse the difference between the two main groups. General Linear Model-Repeated Measures (ANOVA GLM-RM) and Friedman analysis were used to analyse the difference between time intervals. Significant differences were determined at p<0.05.

Results

Tooth movement distances were greater in group 2 compared to group 1 at each time point (Table 1). This difference was only statistically significant on day 3 (p=0.001). For both groups, tooth movement was significantly different between each time interval in each group (p=0.041). After day 3, movement for group 1 reduced, while for group 2, this continued to increase until day 7.

Table 1. Comparison of tooth movement distance between Group 1 (control) and group 2 (vitamin E treatment) (n=7/subgroup (day)).

Data are presented as mean±SD.

Day	Tooth movement (mm)		P value^a	P value^b
Day	Group 1	Group 2	P value^a	P value^b
0	0.00±0.00	0.00±000	Baseline	0.041
1	0.25±0.05	0.31±0.13	0.486
3	0.22±0.12	0.50±0.11	0.001
7	0.37±0.20	0.55±0.22	0.1373

p<0.05 – statistically significant. ^aIndependent t-test; ^bANOVA GLM-RM

The number of osteoblasts in group 2 were higher compared with group 1 at each time point (Figure 2A and B; Table 2). These differences were statistically significant (p<0.05). Group 2 showed increased osteoblasts starting from day 0 to day 3, while group 1 had decreased osteoblast after day 3.

Figure 2. Osteoblasts and osteoclasts in rat alveolar bone at 400x magnification.

(A) osteoblasts in group 1 (control); (B) osteoblasts in group 2 (vitamin E treatment); (C) osteoclasts in group 1; (D) osteoclasts in a Howship’s lacuna in group 2.

Table 2. Comparison of number of osteoblasts between Group 1 (control) and group 2 (vitamin E treatment) (n=7/subgroup (day)).

Data are presented as mean±SD.

Day	Number of osteoblasts (n)		P value^a	P value^b
Day	Group 1	Group 2	P value^a	P value^b
0	5.14±1.34	9.21±3.21	0.012	0.001
1	5.29±1.71	9.36±2.38	0.003
3	3.86±1.94	10.14±3.53	0.004
7	5.04±0.95	8.43±1.02	0.002

p<0.05 – statistically significant. ^aMann-Whitney test; ^bFriedman analysis

The number of osteoclasts in group 2 were higher than group 1 except on day 1, but the differences were not significant statistically (Figure 2C and D; Table 3).

Table 3. Comparison of number of osteoclasts between Group 1 (control) and group 2 (vitamin E treatment) (n=7/subgroup (day)).

Data are presented as mean±SD.

Day	Number of osteoclasts (n)		P value^a	P value^b
Day	Group 1	Group 2	P value^a	P value^b
0	0.89±0.48	1.18±0.47	0.393	0.016
1	1.86±0.93	1.79±0.77	0.797
3	1.07±0.91	1.68±0.67	0.109
7	1.82±1.01	2.18±0.93	0.172

p<0.05 – statistically significant. ^aMann-Whitney test; ^bFriedman analysis

Discussion

Orthodontic force causes gradual compression on the periodontal ligament, which leads to circulatory disorders, such as ischemia and hypoxia in the early stage of orthodontic tooth movement¹⁷. Hypoxia and compression caused by orthodontic force stimulate the production of reactive oxygen species and free radicals, which contribute to cellular and tissue damage, especially damaging lipid peroxidation chains¹⁸. Vitamin E is a strong biological antioxidant that has several functions: scavenges free radicals, which inhibit lipid peroxidation and inflammation; protects ischemic tissue and hypoxia; provides immunostimulation^11,19. Norazlina et al. observed the effect of vitamin E supplementation on bone metabolism in mice treated with nicotine. Their study results suggested that vitamin E can increase trabecular bone formation and prevent bone calcium loss by reducing pro-inflammatory cytokines²⁰.

In the present study, it can be seen that both groups showed increased tooth movement distance as well as increase in the number of osteoclast and osteoblast cells on day 1. This is due to the initial phase of tooth movement after application of orthodontic force²¹. This phase occurs 24 hours to 48 hours after application of orthodontic force on teeth³.

Our results showed that the number of osteoclasts is higher in group 2 compared to group 1 although the difference was not statistically significant. Miresmaeili et al., in their study on the effect of vitamin C to orthodontic tooth movement, found that osteoclast numbers were significantly higher in the vitamin C group, which hence accelerates tooth movement²². Kale et al., in their research on vitamin D injection, observed a significant amount of Howhip’s lacunae in resorption cavity as a result of osteoclast’s activity²³. Future research is required to observe the comparison between Howship’s lacunae and osteoclasts numbers.

In our study, there were statistically significant differences in the mean number of osteoblast cells between both groups at each time observed. Kawakami and Takano-Yamamoto demonstrated an increased osteoclast and osteoblast number with local injection of 1,25-dihydroxyvitamin D3 in the submucosal palatal area of rats subjected to tooth movement on day 7. Increased osteoblast counts were observed on day 14^19,24. In another study, Feresin et al. reported that the formation rate and bone volume increased significantly by 65% in rat bone, who were given a vitamin E diet compared to the control group. Their result indicated that a vitamin E diet was able to increase the process of mineralization and bone formation mediated by osteoblast cells²⁵. Diravidamani et al. stated that many drugs that are used to reduce pain had effects on orthodontic tooth movement. Further research should be done to observe vitamin E on pain regulation, because it has anti-inflammatory effect, which is assumed to reduce pain in orthodontic treatment^10,26–28.

The force mechanism from the separator used in our study was static and the elasticity from the separator is easily lost due to saliva acidity (pH), food and chewing process; a the force of a rubber separator will be reduced by 50–55% within 24 hours²⁹. This is a limitation of our study, as we wanted to analyse for a longer time and with a larger force. The aim of our study was to see the orthodontic tooth movement and not stabilization, so we decided to observe the orthodontic movement within the initial phase, and not all phases until the stabilization phase.

Conclusions

Our findings demonstrated that vitamin E accelerates tooth movement and stimulates bone formation. The number of osteoblast cells in the vitamin E supplemented group is significantly higher than those in the non-vitamin E group. Further studies are needed to evaluate the effect of different doses and types of vitamin E.

Data availability

Underlying data

Open Science Framework: Methods, Figures, and Results from "Effect of Vitamin E Supplementation on Orthodontic Tooth Movement in Wistar Rats, https://doi.org/10.17605/OSF.IO/3S4QB³⁰.

Reporting guidelines

Open Science Framework: ARRIVE checklist for ‘Effect of vitamin E supplementation on orthodontic tooth movement in Wistar rats’, https://doi.org/10.17605/OSF.IO/3S4QB³⁰.

Data are available under the terms of the Creative Commons Attribution 4.0 International license (CC-BY 4.0).

Faculty Opinions recommended

References

1. Krisnan V, Davidovitch Z: Cellular, Molecular, and Tissue-Level Reactions to Orthodontic Force. Am J Orthod Dentofacial Orthop. 2006; 129(4): 469.e1–32. PubMed Abstract | Publisher Full Text
2. Nimeri G, Kau CH, Abou-Kheir NS, et al.: Acceleration of Tooth Movement During Orthodontic Treatment-A Frontier in Orthodontics. Prog Orthod. 2013; 14: 42. PubMed Abstract | Publisher Full Text | Free Full Text
3. Ariffin SHZ, Yamamoto Z, Abidin IZZ, et al.: Cellular and Molecular Changes in Orthodontic Tooth Movement. ScientificWorldJournal. 2011; 11: 1788–803. PubMed Abstract | Publisher Full Text | Free Full Text
4. Bhalaji SI: Orthodontics: The Art and Science. New Delhi: Arya (MEDI) Publishing House, 4^thed, 2009; 400–2. Reference Source
5. Mavragani M, Brudvik P, Selvig KA: Orthodontically Induced Root and Alveolar Bone Resorption: Inhibitory Effect of Systemic Doxycycline Administration In rats. Eur J Orthod. 2005; 27(3): 215–25. PubMed Abstract | Publisher Full Text
6. Alansari S, Sangsuwon C, Vongthongleur T, et al.: Biological Principles Behind Accelerated Tooth Movement. Seminars in Ort. 2015; 21(3): 161–61. Publisher Full Text
7. Asiry MA: Biological Aspects of Orthodontic Tooth Movement: A Review of Literature. Saudi J Biol Sci. 2018; 25(6): 1027–1032. PubMed Abstract | Publisher Full Text | Free Full Text
8. Isola G, Matarese G, Cordasco G, et al.: Mechanobiology of The Tooth Movement During The Orthodontic Treatment: A Literature Review. Minerva Stomatol. 2016; 65(5): 299–304. PubMed Abstract
9. Basaran G, Ozer T, Kaya FA, et al.: Interleukine-1beta and tumor necrosis factor-alpha levels in the human gingival sulcus during orthodontic treatment. Angle orthod. 2006; 76(5): 830–36. PubMed Abstract
10. Uysal T, Amasyali M, Olmez H, et al.: Stimulation of Bone Formation in The Expanding Inter-premaxillary Suture by Vitamin E, In Rat. Korean J Orthod. 2009; 39(5): 337–48. Publisher Full Text
11. Esenlik E, Naziroglu M, Acikalin C, et al.: Vitamin E Supplementation Modulates Gingival Crevicular Fluid Lipid Peroxidation and Antioxidant Levels in Patients With Orthodontic Tooth Movement. Cell Biochem Funct. 2012; 30(5): 376–81. PubMed Abstract | Publisher Full Text
12. Xu H, Watkins BA, Seifer MF: Vitamin E Stimulates Trabecular Bone Formation and Alters Epiphyseal Cartilage Morphometry. Calcif Tissue Int. 1995; 57(4): 293–300. PubMed Abstract | Publisher Full Text
13. Kirschneck C, Bauer M, Gubernator J, et al.: Comparative Assessment of Mouse Models for Experimental Orthodontic Tooth Movement. Sci Rep. 2020; 10(1): 12154. PubMed Abstract | Publisher Full Text | Free Full Text
14. ARRP: Guideline 20: Guidelines for Housing of Rats in Scientific Institutions. Animal Welfare Branch. (www.animalethics.org.au): 16–55. Reference Source
15. Sastroasmoro S, Ismael S: Dasar-Dasar Metodologi Penelitian Klinis. 5^th ed. Sagung Seto. 2014; 352–368. Reference Source
16. Vanjari K, Nuvvula S, Kamatham R: Prediction of Canine and Premolar Size Using the Widths of Various Permanent Teeth Combinations: A Cross-Sectional Study. Contemp Clin Dent. 2015; 6(Suppl 1): S210–20. PubMed Abstract | Publisher Full Text | Free Full Text
17. Arai C, Nomura Y, Ishikawa M, et al.: HSPA1A is upregulated in periodontal ligament at early stage of tooth movement in rats. Histochem Cell Biol. 2010; 134(4): 337–43. PubMed Abstract | Publisher Full Text
18. Zhang L, Wei W, Xu J: Inhibitory Effect of Melatonin on Diquat-Induced Lipid Peroxidation in Vivo as Assessed by the Measurement of F₂-Isoprostanes. J Pineal Res. 2006; 40(4): 326–31. PubMed Abstract | Publisher Full Text
19. Arjmandi BH, Juma S, Beharka A, et al.: Vitamin E Improves Bone Quality in the Aged but Not in Young Adult Male Mice. J Nutr Biochem. 2002; 13(9): 543. PubMed Abstract | Publisher Full Text
20. Norazlina M, Lee PL, Lukman HI, et al.: Effects Of Vitamin E Supplementation On Bone Metabolism In Nicotine-Treated Rats. Singapore Med J. 2007; 48(3): 195–9. PubMed Abstract
21. Noda K, Nakamura Y, Kogure K, et al.: Morphological Changes in the Rat Periodontal Ligament and Its Vascularity After Experimental Tooth Movement Using Superelastic Forces. Eur J Orthod. 2009; 31(1): 37–45. PubMed Abstract | Publisher Full Text
22. Miresmaeili A, Mollaei N, Azar R, et al.: Effect of Dietary Vitamin C on Orthodontic Tooth Movement in Rats. J Dent (Tehran). 2015; 12(6): 409–13. PubMed Abstract | Free Full Text
23. Kale S, Kocadereli I, Atilla P, et al.: Comparison of the effects of 1,25 dihydroxycholecalciferol and prostaglandin E₂ on orthodontic tooth movement. Am J Orthod Dentofacial Orthop. 2004; 125(5): 607–614. PubMed Abstract | Publisher Full Text
24. Kawakami M, Takano-Yamamoto T: Local Injection of 1,25-Dihydroxyvitamin D₃ Enhanced Bone Formation for Tooth Stabilization After Experimental Tooth Movement in Rats. J Bone Miner Metab. 2004; 22(6): 541–6. PubMed Abstract | Publisher Full Text
25. Feresin RG, Johnson SA, Elam ML, et al.: Effects of Vitamin E on Bone Biomechanical and Histomorphometric Parameters in Ovariectomized Rats. J Osteoporos. 2013; 2013: 825985. PubMed Abstract | Publisher Full Text | Free Full Text
26. Diravidamani K, Sivalingam SK, Agarwal V: Drugs Influencing Orthodontic Tooth Movement: An Overall Review. J Pharm Bioall Sci. 2012; 4(Suppl 2): S299–303. PubMed Abstract | Publisher Full Text | Free Full Text
27. Jiang Q: Natural forms of vitamin E: metabolism, antioxidant and anti-inflammatory activities and the role in disease prevention and therapy. Free Radic Biol Med. 2014; 72: 76–90. PubMed Abstract | Publisher Full Text | Free Full Text
28. Long SJ, Benton D: Effects of vitamin and mineral supplementation on stress, mild psychiatric symptoms, and mood in nonclinical samples: a meta-analysis. Psychosom Med. 2015; 75(2): 144–153. PubMed Abstract | Publisher Full Text
29. Weissheimer A, Locks A, Macedo de Menezes M, et al.: In Vitro Evaluation of Force Degradation of Elastomeric Chains Used in Orthodontics. Dental Press J Orthod. 2013; 18(1): 55–62. PubMed Abstract | Publisher Full Text
30. Sufarnap E: Methods, Figures, and Results from "Effect of Vitamin E Supplementation on Orthodontic Tooth Movement in Wistar Rats. 2020. http://www.doi.org/10.17605/OSF.IO/3S4QB
