Case Report
Revised

Case Report: A case of a multivisceral echinococcosis with atypical localization

[version 5; peer review: 2 approved]
PUBLISHED 26 Sep 2024
Author details Author details
OPEN PEER REVIEW
REVIEWER STATUS

Abstract

Hydatidosis is a pathology that is still common. Hydatid cysts commonly involves the liver and lung. Cases of multi visceral echinococcosis with atypical localization are rare. We, herein, report the case of a 53-year-old Maghrebi farmer with multiple organ hydatidosis including 13 hydatid cysts involving the lungs, the liver, the left heart ventricle, the left kidney, the abdomen cavity, the muscles (psoas, adductors), and the subcutaneous gluteal area. The majority of these cysts were already treated surgically, and some of them were due to be removed.

Keywords

Hydtidosis, multi visceral, muscles

Revised Amendments from Version 4

We added information about the consent of the patient.

See the authors' detailed response to the review by Faisal Ahmed

Background

Hydatidosis is an anthropozoonosis caused by the larval form of Echinococcus spp., which live in the gut of dogs, wild canines and other carnivorous animals.1 Humans become the accidental intermediate hosts by ingesting Taenia spp. eggs. Echinococcus spp. are endemic in many countries where sheep, dogs and humans live in close contact.1

All the organs in the human body may be affected by hydatid disease. Hydatid cysts resulting from Echinococcus granulosus commonly involve the liver and lungs2; however may also be found in other unusual organs, including the brain, the heart, and the bones.

If ruptured into the left-sided cardiac chambers, hydatid cysts may cause systemic emboli and when ruptured into the right-sided cardiac chambers, they may cause pulmonary emboli.2

Cases of multi visceral echinococcosis with atypical localization are rare.3 We report here the case of a male patient with 13 hydatid cysts, including the lungs, the heart, the muscles, the liver, the kidney, and the abdomen cavity. This case report aimed to highlight the difficulties of dealing with these multiple locations.

Case report

This is the case of a 53-year-old maghribi male farmer. This patient, with no personal or family history, was referred to the pulmonology department from the department of abdominal surgery, twelve years following the lung surgery, for the management of hemoptysis appearing since few days.

At the time of the clinical encounter, the patient had no additional subjective complaints expect for right lower limb paresthesia resulting from the formation of muscle cysts and persistent post-surgical drainage.

The physical exam showed no neurological deficit and the absence of clinical repercussions of hemoptysis.

The patient was followed up at the department of abdominal surgery, a multiple organ hydatidosis including 13 hydatid cysts were discovered: the lungs, the liver ( Figure 1), the left heart ventricle, the left kidney (Figure 2), the abdomen cavity, the muscles (psoas, adductors), and the subcutaneous gluteal area. In fact, the patient has been experiencing at the beginning a bronchial syndrome symptom, including coughing, and hemoptysis. The laboratory tests were performed and were within the normal range except for high hydatid serology. A Chest CT scan showed three lungs’ cysts. With the exception of the psoas cyst, which is associated with a lower limb paresthesia, the remaining cyst locations identified above were discovered during the preoperative search for additional cysts sites.

Those cysts were treated surgically (Table 1). The patient has received oral Albendazole 400 mg twice-daily for 2 years for discontinuous period.


Figure 1. Axial chest scan passing through the liver showing a CE1 (unilocular) type hydatid cyst according to the WHO classification, of segment 8 of the liver (yellow arrow).


Figure 2. Axial computed tomography scans passing through the thorax in the mediastinal window and through the kidneys and coronal through the kidneys after injection of iodinated contrast product: Calcified hydatid cyst of the lateral wall of the left ventricle (blue arrow). Partially calcified multivesicular hydatid cyst with left endo and exo renal development (the daughter cyst sign) (yellow arrow).

Table 1. Different types of organ involvement.

OrganLocationSizeTreatmentNotes
Lungs1) Right lungs25×20 mmSurgical
a) Left inferior lobeN/AWedge resection
b) Left superior lobe60 mmPartially removed surgically
LiverSegment VIII33×21 mmPartially removed surgicallyBetween superior left and middle hepatic vein.
Segment V53×40 mmSurgical removal+ CholecystectomyTight adhesion with cystic bladder and right portal vein.
KidneyLeft kidney10×80×79 mmSurgical drainage
HeartLeft ventricle30 mmSurgical (thoracotomy)
MusclesPsoas
Adductor
Gluteus
55×34 mm and 40×25 mm
20 mm
Surgical drainage
SubcutaneousGluteal15 mmSurgical
Abdomen cavityParieto colic gutter60 mmSurgical
Abdomen cavityParietal peritoneumBilobedSurgical

The actual Chest CT scan, performed as part of the etiological assessment of hemoptysis, revealed fluid-density endo-bronchial material in the right superior lobe (lung cavity sequelary to the previous cystectomy) separated from the cavity wall by airspace (“air crescent” sign). This image was typical of pulmonary aspergilloma (Figure 3). Although the Aspergillus serology showed doubtful results, the clinical context together with the CT scan findings were highly suggestive of a pulmonary aspergilloma. Blood tests showed high levels of IgE. A surgical resection of the cavity was scheduled but not yet performed.


Figure 3. Axial chest scan passing through the thorax in the parenchymal window and after injection of iodinated contrast product showing a fluid-density endo-bronchial material in the right superior lobe of the lung with an “air crescent” sign: pulmonary aspergilloma (blue arrow).

During the follow-ups period no recurrence of cysts occurred since the last cysts surgery. The patient was followed up at the outpatient clinic monthly while using medical treatment then every year once all cysts are removed.

Discussion

This case emphasizes the possibility of treating multiple locations of hydatid cyst with a good vital prognosis. In fact, hydatid cysts remain an important health issue in Tunisia that affects both humans and animals, especially in rural areas.

The annual incidence of hydatidosis is 11.3 per 100000 inhabitants.1 When humans consume Taenia spp. Eggs released from dogs, they unintentionally become infected especially when they are in contact with sheep and dogs1 like the case of this patient who is a farmer. This condition increased his vulnerability to the illness.

Usually, hydatidosis presents as a single cyst involving the liver or the lungs, but multiple organs may be affected in some cases.3 In our case we are reporting multiple atypical locations including the heart, the kidney, the muscles, and the subcutaneous tissue. The simultaneous coexistence of cysts in these locations simultaneously is rarely described in the literature.4 In the present paper, focus was not put on the liver and the lungs as they are the classic location of this parasitosis, and they are commonly reported in the literature. It was rather put on the other locations.

Heart involvement is uncommon and accounts for less than 0.5% of the cases, it is usually a part of disseminated infection.5 This localization is potentially fatal without surgical treatment but thanks to the improvement in surgical techniques, its morbidity has declined drastically.5 The patient underwent open heart surgery to remove a left ventricular wall cyst. Post-surgical echocardiography revealed no local recurrence and no abnormalities.

Invasion of the myocardium usually occurs hematogeniously through the coronary arteries and since the majority of the population have a left dominant circulation, the left ventricle is the most commonly involved part of the heart (60%),5 Another possible explanation is the dissemination from the lungs either following a pulmonary vein rupture and migration of the cysts6 or by a direct contact with hydatid cysts originating from the lung.7

Renal involvement is also rare (2–3%) and it is usually associated with disseminated disease, they are most commonly asymptomatic, as reported in the present case. The diagnosis was made by an abdominal CT scan which has a sensitivity of 98% in diagnosing hydatid disease.8

Psoas cysts are also uncommon.9 The patient presented with two psoas cysts, a finding that has never been reported in the literature.

The patient has also presented with a 30-mm gluteal subcutaneous cyst, this involvement was described in rare cases in the literature.10 Patients usually have a painless palpable mass of at least 3 months, and it is usually larger than 3 cm, as it is reported in the present case.11 Subcutaneous cysts tend to involve the trunk and the limb roots, possibly due to the rich vascularization and the relatively lower activity of the muscle in these areas.12

The patient has received oral Albendazole 400 mg twice-daily for 2 years for discontinuous periods in the pre and postoperative period since the patient was operated on several times.13 This duration was suggested by the infectious diseases team.14

Although, surgery is the primary treatment for echinococcosis. Albendazole is also recommended for inoperable patients with liver or lung cysts and for patients with multiple cysts in two or more organs in order to sterilize the cyst and lower the risk of allergy or recurrence14 but optimal duration have never been formally assessed.13 A long duration treatment is recommended especially if there is cardiac involvement and a disseminated disease.14

Another intriguing finding in this case report was the discovery of an aspergilloma, on the lung cavity. Pulmonary aspergilloma occurs as a colonizer of pre-existing pulmonary cavity of any etiology such as tuberculosis sequelae, cavitary neoplasia or operated hydatid cyst and it is a saprophytic infection.15 Aspergilloma has rarely been described in operated hydatid cyst cavities in immunocompetent patients.16 For this patient, the aspergilloma was discovered twelve years after the lung surgery. A very similar case of a 56-year-old patient, who presented with an aspergilloma of the upper right lobe following cystectomy, have been reported by M. El Hammoumi et al.16 Surgical resection is recommended as a radical treatment for aspergilloma, as was the case with this patient.16

This case highlights the necessity of investigating additional sites for hydatid cysts, even when the patient is asymptomatic. It also demonstrates that timely and appropriate surgical intervention is the gold standard for achieving optimal outcomes.14 A Long-term follow-up is recommended to early identify complications, every 3–6 months initially and every year once the situation is stable.14

Conclusion

Multiple hydatidosis is a rare condition that can endanger vital and functional prognosis. Imaging is essential for diagnosis and for the assessment of extension and the detection of asymptomatic localization to ensure early treatment. The recommended treatment for these numerous cysts comprises of both radical surgery and medical treatment; conservative surgery is discouraged in order to lower the risk of recurrence. Prevention remains the best strategy to avoid hydatid cysts.

Author contributions

NF, AM and AM actively involved in data collection and processing. RK and MJ were involved in manuscript preparation. HB, AB, SJ, SCH, NR, and FM were involved in manuscript reviewing. All authors have read and approved the manuscript.

Consent

Written informed consent was received from the patient to publish his clinical details and images.
